Level 2 k8orized Image: Package Layer Optimization for Kubernetes
Mars Marni
Raj Mars Marni
Description of the image

Building upon the foundation laid by Level 1 k8orization, Level 2 dives deeper, focusing on Package Layer k8orization. This process targets the pre-installed packages within the OS image, further refining and optimizing them for Kubernetes deployments.

What is Package Layer k8orization?

It's the meticulous analysis and transformation of pre-installed software packages within the k8orized OS image. This level focuses on two key aspects:

1. File Optimization:

  • Unnecessary Component Removal: Redundant files, configurations, and documentation within package installations are eliminated, reducing image size and minimizing potential attack vectors.

  • Library Trimming: Unused libraries and dependencies within packages are identified and removed, further shrinking the image footprint and optimizing resource utilization.

2. Enhanced Security and Monitoring:

  • System Call Restrictions: Identical restrictions implemented in Level 1 are applied at the package level, further limiting unauthorized actions and bolstering security.

  • Application-Level Logging: Comprehensive logging mechanisms are integrated into packages, enabling detailed monitoring of application behavior and troubleshooting potential issues.

3. Abstraction Layer with Infrastructure Integration:

This step introduces a C, Python or Go abstraction layer and acting as a bridge between the Package and the underlying K8s infrastructure. The key purpose of this layer is to enhance security, portability, and extensibility, simplifying integration with various cluster-native tools and services:

  • Universal Compatibility: The abstraction layer decouples the application from the specifics of the underlying Package, enabling seamless deployment across different K8s environments.

  • Automated Configuration Management: Imagine your K8s cluster as a complex ecosystem with tools like secret management, DNS configuration, and network connectivity providers. This Package abstraction layer can act as a "smart orchestrator", automatically enabling Package configurations for products, tools, and services.

  • Simplified Maintenance and Upgrades: With streamlined configurations managed by the Package abstraction layer, updates and maintenance become easier.

  • Improved Operational Efficiency: By automating tedious Package configuration tasks, human intervention is minimized, freeing up your team to focus on other higher-level development and operational activities.

  • Think of this Package abstraction layer as a "universal package translator" for your K8s environment. It takes away the burden of intricate Package configurations and interdependencies, leaving you with a secure, flexible, portable, and easily maintainable Package layer for your K8s ecosystem.

This document presents an example hGraph visualization of the package k8orization process implemented at BOTops company.

Sector 1:

The user authorization process requires accessing and verifying credentials across all necessary services: Google, AWS, Jira, Miro, Toggle Tracker, GitHub, and DockerHub.

Sector 2:

This sector outlines the creation of manifest files in YAML format for various Kubernetes products.

  • The first manifest defines a StorageClass, enabling volume creation.

  • The second manifest creates a PersistentVolumeClaim, claiming a volume.

  • The third manifest deploys a service with mounted volumes, exposing both /mnt and /usr directories.

  • The fourth manifest deploys another service with mounted volumes, focusing specifically on volumes within the /usr directory.

Sector 3:

Section 3 outlines the pre-deployment steps, including authorizing access to a Jump EC2 instance, establishing a connection to the EKS cluster, switching to the appropriate namespace, and verifying connectivity to the Node Group, ensuring a smooth and secure deployment process.

Sector 4:

Section 4 dives into deploying the StorageClass, detailing the steps: uploading the manifest file, establishing the StorageClass itself, and the subsequent automatic volume creation, streamlining storage provisioning for your application.

Sector 5:

Section 5 outlines the deployment of the PersistentVolumeClaim (PVC), guiding you through uploading the manifest file and subsequent PVC creation. This empowers your application to request and utilize persistent storage seamlessly.

Sector 6:

Section 6 delves into the deployment process, guiding you through applying the deployment manifest, creating the deployment resource, spawning a replica set, and finally launching individual pods, orchestrating the entire application rollout in a step-by-step manner.

Sector 7:

Section 7 tackles automated pod storage attachment, demonstrating how to specify StorageClass and PersistentVolumeClaim information within your manifest file. This ensures seamless storage provisioning for your deployed pods.

Sector 8:

Section 8 dives into content migration, guiding you through executing the created pod, copying all files from /usr to the mounted /mnt directory, and then verifying memory usage remains consistent across both directories. This final step confirms successful migration and data persistence within the mounted volume.

Sector 9:

Sector 9 streamlines resource removal with the deployment manifest deletion, triggering a cascading process that automatically deletes the associated pods, replica set, and ultimately the deployment itself.

Sector 10:

Section 10 showcases deployment with a dedicated volume for the /usr directory. It walks you through applying a deployment manifest, spawning a replica set, and launching individual pods, all configured with the mounted volume.

Sector 11:

Sector 11 focuses on automated storage provisioning for deployed pods. This triggers the automatic attachment of the storage resources to the created pod.

Sector 12:

This section details the installation process of essential software packages for the system. It covers the installation of pip, cassio, python-dotenv, llama_index, and openai. Each package installation is accompanied by the generation of log files for tracking purposes.

Why Do We Do It?

Standard Docker images package software with unnecessary components, including documentation, legacy files, and unused libraries. This adds unnecessary weight and introduces potential vulnerabilities. Level 2 k8orization addresses these issues by:

  • Further Reduced Image Size: Smaller images translate to faster downloads, deployments, and lower storage costs.

  • Enhanced Security: Removing unused elements restricts attack surfaces and bolsters your security posture.

  • Optimized Resource Utilization: Smaller size and targeted functionality lead to less CPU, memory, and disk consumption within your K8s cluster.

  • Improved System Stability: Trimming excess components mitigates potential conflicts and stability issues.

How is it Useful?

k8orized package layers offer several benefits for your K8s deployments:

  • Faster Deployments and Updates: Smaller images mean quicker download and startup times, minimizing deployment downtime and accelerating updates.

  • Enhanced Cluster Scalability: Denser deployments are possible thanks to smaller images, leading to optimal resource utilization within your cluster.

  • Simplified Security Management: Consistent package configurations across deployments streamline security updates and vulnerability management.

  • Streamlined Troubleshooting: Application-level logging facilitates easier identification and resolution of issues within your applications.

Differences from Standard Images:

k8orized package layers differentiate themselves from standard Docker images in multiple ways:

  • Targeted Optimization: They analyze and remove unnecessary elements within packages, leading to a highly optimized footprint.

  • Enhanced Security Focus: System call restrictions and application-level logging go beyond standard Docker images, resulting in a secure environment.

  • Kubernetes-Specific Design: They are explicitly tailored for K8s deployments, considering resource utilization and security within that context.
